With Lock Type/Without Lock Type
Categories:
Compliance Credentials: Strictly certified to UL 260 and FM standards for high-hazard critical infrastructure
TEL：
With Lock Type/Without Lock Type
Technical Features
Size: DN15-DN50/ 0.5"-2”"
Working Pressure: 200PSI / 300PSI/ PN10/ PN16Design Standard: API608
Test Standard: API598
Connection Standard:ASME B1.20.1/BS EN10226-1/GB/T 7307
Working Temperature: -20 to 180°℃FM/UL Approved
Valve Material List
|
NO. |
Name |
Qtv |
Material |
|
1 |
Handle sleeve |
1 |
PVC |
|
2 |
Cland |
1 |
S20100/S30400/S31600 |
|
3 |
Packing |
1 |
PTFF |
|
4 |
Stem |
1 |
S20100/S30400/S31600 |
|
5 |
Thrust washer |
1 |
PTFE |
|
6 |
Body |
1 |
CF8/CF8M |
|
7 |
Ball |
1 |
CF8/CF8M |
|
8 |
End cap |
1 |
CF8/CF8M |
|
9 |
Seat |
2 |
PTFE |
|
10 |
Gasket |
1 |
PTFE |
|
11 |
Haodle(\ocK) |
1 |
S20100/S30400/S31600/Steel |
|
12 |
Nut |
1 |
S20100/S30400/S31600 |
|
13 |
Lock Block |
1 |
S20100/S30400/S31600/Steel |
Dimensions
|
DN |
INCH |
D |
L |
E |
H |
|
15 |
0.5" |
15 |
64.5 |
100 |
58 |
|
20 |
0.75" |
20 |
77 |
100 |
62 |
|
25 |
1" |
25 |
85 |
126 |
68 |
|
32 |
1.25" |
32 |
100 |
126 |
75 |
|
40 |
1.5" |
38 |
111 |
150 |
89 |
|
50 |
2" |
50 |
124 |
150 |
97 |
