Resilient Wedge NRS Gate Valve - Grooved End Z85-300
Technical Features
Nominal Pressure: 300PSI
Groove Standard: Metric or ANSI/AWWA C606
Face to Face Standard: ASME B16.10
Sizes: 2½", 3", 4", 5", 6", 8", 10", 12"
Approvals: FM, UL, CUL, NSF /ANSI 61 & NSF / ANSI 372
Maximum Working Pressure: 300PSI (Maximum Testing Pressure: 600PSI) conforms to UL262, ULC/ORD C262-92 , FM 1120/ 1130
Maximum Working Temperature: 80°C/176°F
Coating Details: Epoxy coated interior and exterior by Electrostatic Spray or Coating upon request
NPT plug on body with 2 operating nuts
Certified lead-free by NSF /ANSI 61 & NSF/ANSI 372 is available
Valve Material List
NO. |
Name |
Material |
1 |
Flat washer |
Steel 1045 or Stainless Steel 304 |
2 |
Hexagon Socket Screw |
Steel 1045 or Stainless Steel 304 |
3 |
Sealing Ring |
FPDM |
4 |
O-ring |
EPDM |
5 |
Sealing Ring |
EPDM |
6 |
O-ring |
EPDM |
7 |
Bonnet |
Ductile Iron |
8 |
Stem |
Stainless Steel 304 or Steel C95400 |
9 |
Plug |
Stainless Steel 304 or Steel C95400 |
10 |
Disc |
Ductile Iron +EPDM |
11 |
Body |
Ductile Iron |
12 |
Sealing Ring |
EPDM |
13 |
Retaining Ring |
C95400 |
14 |
Gland |
Ductile Iron |
15 |
post Flange |
Ductile Iron |
16 |
Wrench Nut |
Ductile Iron |
17 |
Bolt |
Stainless Steel 304 or Steel1045 |
18 |
Washer |
Stainless Steel 304 or Steel 1045 |
19 |
Hexagon Socket Screw |
Steel 1045 or Stainless Steel 304 |
20 |
Stem Nut |
CF8 or C95400 |
Dimensions
Size |
DN |
L |
F |
D |
E |
G |
H |
2½" |
65 |
190 |
15.9 |
73 |
69.1 |
7.9 |
292 |
76.1 |
72.3 |
||||||
3" |
80 |
203 |
15.9 |
88.9 |
84.9 |
7.9 |
322 |
4” |
100 |
229 |
15.9 |
114.3 |
110.1 |
9.5 |
342 |
5” |
125 |
254 |
15.9 |
139.7 |
135.5 |
9.5 |
412 |
141.3 |
137 |
||||||
6" |
150 |
267 |
15.9 |
165.1 |
160.8 |
9.5 |
448 |
168.3 |
163.9 |
||||||
8” |
200 |
292 |
19 |
216.3 |
211.6 |
11.1 |
534 |
219.1 |
214.3 |
||||||
10” |
250 |
330 |
19 |
273 |
268.3 |
12.7 |
635 |
12” |
300 |
356 |
19 |
323.9 |
318.3 |
12.7 |
720 |
